DPX is a new series of ultra-lightweight power amplifiers able to offer to professional entertainers a huge amount of power and the maximum performance and portability in a very affordable package.Thanks to the high-density Class D technology employed in the DPX’s output stages, we’ve been able to build very powerful amplifiers in an ultra-compact and lightweight package. The extremely efficient switch mode power supply (SMPS) helps to reduce further the weight, while using much less energy with a direct benefit to the environment.All models feature a built-in 24dB/octave stereo crossover with BI-AMP and HIGH-PASS options, for easily filtering a 2-way system without the need of additional outboard. Fast-attack precise CLIP LIMITERS guarantee maximum output without distortion, while a comprehensive protection system safeguards both the speakers and the amplifier.The electronics is hosted in a feather-light all-aluminum case, able to provide an efficient cooling and, at the same time, protection and durability over the years.DPX are power amplifiers offering extraordinary value to entertainers, DJ and sound engineers looking for massive output, excellent performance and absolute portability.
| Power 8 ohm* | 350 |
| Power 4 ohm** | 500 |
| Power BRIDGE 8 ohm** | 1000 |
| * W RMS per channel, both channel driven, 1KHz THD 1%, ** 40ms burst | |
| Output Stage | Class D |
| Frequency Response | 20 Hz – 20 kHz |
| Input Impedance | 10 kΩ unbalanced, 20 kΩ balanced |
| Damping Factor | >60 |
| S/N Ratio (Unweighted) | >102 dB |
| Input Connectors | XLR F (INPUT), XLR F (LINK) |
| Output Connectors | SPEAKON |
| Controls | INPUT LEVEL, STEREO/BRIDGE-PARALLEL, FLAT/BI-AMP/HPF |
| LED Indicators | 7-LED BAR (ON, LIMIT, PROTECTION, -5dB / -10dB / -20dB / -40dB SIGNAL) |
| Cooling | Variable speed DC fan, air flow from front to rear |
| Protections | AC low power, DC, thermal, short circuit, VHF, CLIP limiter |
| Power Supply | 230 VAC 50 Hz or 120 VAC 60 Hz |
| Dimensions (W x H x D) | 483 x 89 x 382 mm |
| Weight | 5 Kg (11 lb) |
DPX is a new series of ultra-lightweight power amplifiers able to offer to professional entertainers a huge amount of power and the maximum performance and portability in a very affordable package.Thanks to the high-density Class D technology employed in the DPX’s output stages, we’ve been able to build very powerful amplifiers in an ultra-compact and lightweight package. The extremely efficient switch mode power supply (SMPS) helps to reduce further the weight, while using much less energy with a direct benefit to the environment.All models feature a built-in 24dB/octave stereo crossover with BI-AMP and HIGH-PASS options, for easily filtering a 2-way system without the need of additional outboard. Fast-attack precise CLIP LIMITERS guarantee maximum output without distortion, while a comprehensive protection system safeguards both the speakers and the amplifier.The electronics is hosted in a feather-light all-aluminum case, able to provide an efficient cooling and, at the same time, protection and durability over the years.DPX are power amplifiers offering extraordinary value to entertainers, DJ and sound engineers looking for massive output, excellent performance and absolute portability.
| Power 8 ohm* | 350 |
| Power 4 ohm** | 500 |
| Power BRIDGE 8 ohm** | 1000 |
| * W RMS per channel, both channel driven, 1KHz THD 1%, ** 40ms burst | |
| Output Stage | Class D |
| Frequency Response | 20 Hz – 20 kHz |
| Input Impedance | 10 kΩ unbalanced, 20 kΩ balanced |
| Damping Factor | >60 |
| S/N Ratio (Unweighted) | >102 dB |
| Input Connectors | XLR F (INPUT), XLR F (LINK) |
| Output Connectors | SPEAKON |
| Controls | INPUT LEVEL, STEREO/BRIDGE-PARALLEL, FLAT/BI-AMP/HPF |
| LED Indicators | 7-LED BAR (ON, LIMIT, PROTECTION, -5dB / -10dB / -20dB / -40dB SIGNAL) |
| Cooling | Variable speed DC fan, air flow from front to rear |
| Protections | AC low power, DC, thermal, short circuit, VHF, CLIP limiter |
| Power Supply | 230 VAC 50 Hz or 120 VAC 60 Hz |
| Dimensions (W x H x D) | 483 x 89 x 382 mm |
| Weight | 5 Kg (11 lb) |
