After providing for years thousands of satisfied users with the best mixing tools, we have decided to renovate our M Series with an assortment of novelties. The new M compact mixers have been updated with improved features and repacked into a new stylish package. While keeping the superior audio quality, the full set of features and the highest number of MIC inputs in the category that have been the hallmarks of our M Series, we have added extra ‘intelligent’ functions, such as USB routing and channel COMPRESSORS. All the models feature the new PROEL 24bit PROFEX DSP, one of the fi nest digital eff ect of its class, providing 256 studio-grade algorithms (including mono and stereo TAP DELAY and TAP DELAY + REVERB) and a convenient LCD display. Designed and engineered in Italy by PROEL R&D, M mixers are hosted in an ultra-rugged stylish metal case with ABS sides, providing extended durability for a stage-proof use. As a unique feature in the category, all the models include as standard both a padded carrying bag and metal brackets for 19” rack mounting. The 8-in, 6-mic M822USB now includes a versatile USB routing section, for a complete control of the signals to and from the PC and a built-in universal power supply.
System type: Compact 8-channel 4-bus mixer
Input Connectors:
Mic Input: Balanced XLR-F
Line Input: Balanced JACK
Input Sensitivity:
MONO INPUT CHANNEL – Mic Input: from 0 to -60 dB
MONO INPUT CHANNEL – Line Input: from +20 to -40 dB
STEREO INPUT CHANNEL – Mic Input: -0 / -40 dB
STEREO INPUT CHANNEL – Line Input: +20 / -20 dB
Input Impedance:
MONO INPUT CHANNEL – Mic Input: 2 Kohm
MONO INPUT CHANNEL – Line Input:10 Kohm
STEREO INPUT CHANNEL – Mic Input: 2 Kohm
STEREO INPUT CHANNEL – Line Input: 10 Kohm
Mono Input channel equalization:
HIGH (shelving): ±15 dB @ 12KHz
MID (peaking): ±15 dB @ 2.5KHz
LOW (shelving): ±15 dB @ 80Hz
Stereo Input Channel Equalization:
HIGH (shelving): ±15 dB @ 12KHz
MID (peaking): ±15 dB @ 2.5KHz
LOW (shelving): ±15 dB @ 80Hz
Effects: 256 (16 presets x 16 variations): HALL, ROOM, VOCAL and PLATE reverbs STEREO and MONO TAP DELAY REV + DELAY, REV + TAP DELAY, REV + CHORUS
Crosstalk (meas. at 1 KHz): > 82 dBu
HUM & Noise unweighted: < -93 dBu
THD + Noise at +4dB, 1kHz: < 0,008 %
Power Supply: Internal power supply
Mains Supply Voltage: 110-240 VAC (±10%) 50 / 60 Hz available with
Europe mains cord (Shucko plug),
US mains cord (NEMA 5-15P plug),
UK mains cord (BS1363 plug)
Power consumption: 45 W
Weight: 3.4 lb
Dimensions (W x H x D): 315 x 91 x 363 mm
After providing for years thousands of satisfied users with the best mixing tools, we have decided to renovate our M Series with an assortment of novelties. The new M compact mixers have been updated with improved features and repacked into a new stylish package. While keeping the superior audio quality, the full set of features and the highest number of MIC inputs in the category that have been the hallmarks of our M Series, we have added extra ‘intelligent’ functions, such as USB routing and channel COMPRESSORS. All the models feature the new PROEL 24bit PROFEX DSP, one of the fi nest digital eff ect of its class, providing 256 studio-grade algorithms (including mono and stereo TAP DELAY and TAP DELAY + REVERB) and a convenient LCD display. Designed and engineered in Italy by PROEL R&D, M mixers are hosted in an ultra-rugged stylish metal case with ABS sides, providing extended durability for a stage-proof use. As a unique feature in the category, all the models include as standard both a padded carrying bag and metal brackets for 19” rack mounting. The 8-in, 6-mic M822USB now includes a versatile USB routing section, for a complete control of the signals to and from the PC and a built-in universal power supply.
System type: Compact 8-channel 4-bus mixer
Input Connectors:
Mic Input: Balanced XLR-F
Line Input: Balanced JACK
Input Sensitivity:
MONO INPUT CHANNEL – Mic Input: from 0 to -60 dB
MONO INPUT CHANNEL – Line Input: from +20 to -40 dB
STEREO INPUT CHANNEL – Mic Input: -0 / -40 dB
STEREO INPUT CHANNEL – Line Input: +20 / -20 dB
Input Impedance:
MONO INPUT CHANNEL – Mic Input: 2 Kohm
MONO INPUT CHANNEL – Line Input:10 Kohm
STEREO INPUT CHANNEL – Mic Input: 2 Kohm
STEREO INPUT CHANNEL – Line Input: 10 Kohm
Mono Input channel equalization:
HIGH (shelving): ±15 dB @ 12KHz
MID (peaking): ±15 dB @ 2.5KHz
LOW (shelving): ±15 dB @ 80Hz
Stereo Input Channel Equalization:
HIGH (shelving): ±15 dB @ 12KHz
MID (peaking): ±15 dB @ 2.5KHz
LOW (shelving): ±15 dB @ 80Hz
Effects: 256 (16 presets x 16 variations): HALL, ROOM, VOCAL and PLATE reverbs STEREO and MONO TAP DELAY REV + DELAY, REV + TAP DELAY, REV + CHORUS
Crosstalk (meas. at 1 KHz): > 82 dBu
HUM & Noise unweighted: < -93 dBu
THD + Noise at +4dB, 1kHz: < 0,008 %
Power Supply: Internal power supply
Mains Supply Voltage: 110-240 VAC (±10%) 50 / 60 Hz available with
Europe mains cord (Shucko plug),
US mains cord (NEMA 5-15P plug),
UK mains cord (BS1363 plug)
Power consumption: 45 W
Weight: 3.4 lb
Dimensions (W x H x D): 315 x 91 x 363 mm
