PROEL V FREE systems gives you the freedom to perform your music or play your sound anywhere, with a superb sound quality and without the hassle of laying down cables or finding a power outlet.V10FREE and V12FREE are battery-powered portable sound systems featuring a powerful 400W amplifier, a built-in 3-channel mixer with effect and tone controls and an advanced MP3 player with BLUETOOTH connectivity, featuring a large back-lit LCD display and able to play songs from SD card, USB MEMORY STICK or directly from your smartphone or tablet.
They includes also two USB inputs for connecting PROEL U24H or U24B 2.4GHz Wireless Microphones with USB receiver, available both with handheld and bodypack transmitter. Just plug in the ultra-compact USB receiver and you can instantly use a professional wireless system, offering a high-definition, interference-free transmission thanks to the 2.4GHz technology.
The the premium loudspeakers, the Class D power amplifier and the sophisticated processing provide a superb sound quality, while the built-in Li-ion battery allows for up to 10 hours of mains-free continuous operation, for the maximum freedom of use.
Both these ultra-portable and light-weight systems (10kg and 11kg respectively) can be installed on standard speaker poles and the V12FREE is fitted with a luggage-style extra handle and two wheels.Incredibly simple to set-up and use , V FREE loudspeakers are perfect for a wide range of applications, including parties, schools, corporate and educational presentations, seminars, gym, weddings, live music and even DJ sets.
| MIXER Section | |
| MONO inputs | 2 x MIC/LINE IN (XLR-F + 1.4″ JACK) |
| STEREO input | 1 x LINE IN (2xRCA + MINI-JACK) |
| WIRELESS inputs | 2 x USB TYPE-A |
| Internal EFFECT | ECHO |
| Outputs | MONO LINE OUT (1.4″ JACK) |
| Main EQ | 2-band EQ (HIGH + LOW) |
| MULTIMEDIA Section | |
| Player Type | USB / SD / BLUETOOTH player with BT LINK |
| Compatible File Formats | MP3 |
| Control Interface | LCD display, CONTROL buttons |
| AMPLIFIER Section | |
| Total Peak Power | 400 W |
| Continuous Power | 200 W |
| Amplifier Type | Class D |
| Power Supply | SMPS |
| Processing | Analog |
| LOUDSPEAKER Section | |
| System Type | 2-way vented enclosure |
| High Frequency Device | 1″ horn loaded neodymium compression driver |
| Low Frequency Device | 10” woofer with 1.5” VC |
| Angular Coverage | 90° H x 60° V |
| Frequency Response | 60 Hz – 20 kHz |
| Max SPL | 122 |
| GENERAL Specifications | |
| Construction | Polypropylene |
| Cabinet Colour | Black |
| Handles | 1 x top |
| Wheels | – |
| Mounting Pole | 1 x bottom |
| Dimensions (WxHxD) | 330 x 514 x 286 mm |
| Weight | 10 kg (22.1 lb.) |
| Recharge Battery | 11.1 V / 8000 mAh Li-ion |
| Battery Recharging Time | 4-5 hours |
| Battery Working Time | 10-12 hours |
| Power Supply | 100 V-240 V~ 50/60 Hz |
| Rated Consumption | 300 W |
PROEL V FREE systems gives you the freedom to perform your music or play your sound anywhere, with a superb sound quality and without the hassle of laying down cables or finding a power outlet.V10FREE and V12FREE are battery-powered portable sound systems featuring a powerful 400W amplifier, a built-in 3-channel mixer with effect and tone controls and an advanced MP3 player with BLUETOOTH connectivity, featuring a large back-lit LCD display and able to play songs from SD card, USB MEMORY STICK or directly from your smartphone or tablet.
They includes also two USB inputs for connecting PROEL U24H or U24B 2.4GHz Wireless Microphones with USB receiver, available both with handheld and bodypack transmitter. Just plug in the ultra-compact USB receiver and you can instantly use a professional wireless system, offering a high-definition, interference-free transmission thanks to the 2.4GHz technology.
The the premium loudspeakers, the Class D power amplifier and the sophisticated processing provide a superb sound quality, while the built-in Li-ion battery allows for up to 10 hours of mains-free continuous operation, for the maximum freedom of use.
Both these ultra-portable and light-weight systems (10kg and 11kg respectively) can be installed on standard speaker poles and the V12FREE is fitted with a luggage-style extra handle and two wheels.Incredibly simple to set-up and use , V FREE loudspeakers are perfect for a wide range of applications, including parties, schools, corporate and educational presentations, seminars, gym, weddings, live music and even DJ sets.
| MIXER Section | |
| MONO inputs | 2 x MIC/LINE IN (XLR-F + 1.4″ JACK) |
| STEREO input | 1 x LINE IN (2xRCA + MINI-JACK) |
| WIRELESS inputs | 2 x USB TYPE-A |
| Internal EFFECT | ECHO |
| Outputs | MONO LINE OUT (1.4″ JACK) |
| Main EQ | 2-band EQ (HIGH + LOW) |
| MULTIMEDIA Section | |
| Player Type | USB / SD / BLUETOOTH player with BT LINK |
| Compatible File Formats | MP3 |
| Control Interface | LCD display, CONTROL buttons |
| AMPLIFIER Section | |
| Total Peak Power | 400 W |
| Continuous Power | 200 W |
| Amplifier Type | Class D |
| Power Supply | SMPS |
| Processing | Analog |
| LOUDSPEAKER Section | |
| System Type | 2-way vented enclosure |
| High Frequency Device | 1″ horn loaded neodymium compression driver |
| Low Frequency Device | 10” woofer with 1.5” VC |
| Angular Coverage | 90° H x 60° V |
| Frequency Response | 60 Hz – 20 kHz |
| Max SPL | 122 |
| GENERAL Specifications | |
| Construction | Polypropylene |
| Cabinet Colour | Black |
| Handles | 1 x top |
| Wheels | – |
| Mounting Pole | 1 x bottom |
| Dimensions (WxHxD) | 330 x 514 x 286 mm |
| Weight | 10 kg (22.1 lb.) |
| Recharge Battery | 11.1 V / 8000 mAh Li-ion |
| Battery Recharging Time | 4-5 hours |
| Battery Working Time | 10-12 hours |
| Power Supply | 100 V-240 V~ 50/60 Hz |
| Rated Consumption | 300 W |
