FREETWOX is an all-in-one battery-powered personal PA system featuring multiple inputs, USB PLAYER and BLUETOOTH connectivity. Hosted in a compact, lightweight yet ultra-durable polypropylene cabinet with multiple aiming positions, it represents the perfect solution for musicians, DJs and general PA users.
The coaxial speaker design combines a high-definition 1″ HF compression driver with a powerful 6.5″ LF woofer, delivering balanced and coherent sound, strong projection over distance, and wide audience coverage.
The state-of-the-art electronics includes a sophisticated pre-amp section with DSP processor and a powerful 400W Class D power amplifier. The built-in 2 mono + 1 stereo channel digital mixer allows to connect two microphones or instruments and a stereo player, each one with independent level controls. A 2-band EQ and a studio-grade digital REVERB is also available for microphone/instrument inputs.
The USB player allows you to play MP3 files from a USB flash memory, while the built-in BLUETOOTH audio interface with STEREO LINK capability (TWS) allows to stream high-quality audio from portable devices without the need of any cable.
The built-in Li-ion battery provides up to 10 hours of mains-free continuous operation, for the maximum freedom of use.
| System type | 2-way vented enclosure |
| High Frequency Device | 1x 1″ compression driver coaxial |
| Low Frequency Device | 1 x 6.5″ woofer |
| Frequency response (-3 dB) | 60 Hz – 20 kHz |
| Max. SPL | 114 dB |
| Coverage angle (H x V) | 90° x 60° |
| Total peak power | 400 W |
| HF continuous power | 50 W class D |
| LF continuous power | 150 W class D |
| Input Connectors | 2 x XLR/TRS Combo (balanced) 1 x 6.35mm Jack (balanced) 1 x 3.5mm Jack Stereo 1 x USB-A for PLAYER |
| Output Connectors | 1 x XLR (balanced) 1 x USB-C charge port |
| Input Channels | 2x MIC/GUITAR/LINE 1x BT /USB / STEREO LINE / MONO LINE |
| Controls | CH1/2 LEVEL, HIGH, LOW, REVERB USB PLAY-PAUSE/NEXT/PREVIOUS Bluetooth PAIR / STEREO LINK |
| Processing | DSP |
| Bluetooth | Protocol 5.0, Audio Streaming |
| Enclosure material | Polypropylene |
| Finish | Black Textured |
| Grille material | Powder coated steel |
| Handles | 1 x top |
| Mounting Pole | 1 x bottom |
| Dimensions (H x W x D): | 320 mm x 240 mm x 290 mm 12.59 in x 9.45 in x 11.42 in |
| Weight | 6.5 kg 14.3 lb |
| USB charging | 2 A max |
| Power Supply | 100 – 240 V~, 50 / 60 Hz |
| Consumption | 150 W |
| Battery type | Rechargeable Lithium-ion 6000mAh |
| Battery play time (at medium level) | up to 10 hours |
| Recharging time | less than 4 hours |
